AVAILABLE CLASS / SIZE

TYPE	ANSI CLASS							ACTUATOR
	150LB	300LB	600LB	900LB	1500LB	2500LB	4500LB	P	E	H
GATE	2” ~ 72”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	2” ~ 48”	-	○	○	○
GLOBE	2” ~ 36”	2” ~ 36”	2” ~ 36”	2” ~ 24”	2” ~ 16”	2” ~ 16	-	○	○	○
CHECK	2” ~ 48”	2” ~ 36”	2” ~ 36”	2” ~ 30”	2” ~ 24”	2” ~ 20”	-	-	-	-

TYPE	GATE	GLOBE	CHECK
DESIGN	ASME B16.34	ASME B16.34	ASME B16.34
	API600	API623	API6D
	BS1414	BS1873	BS1868
RATING	#150 up to #2500	#150 up to #2500	#150 up to #2500
SIZE	2” up to 72”	2” up to 36”	2” up to 48”
TEMPERATURE(℃)	-29 up to 270 (Soft seat)	-29 up to 270 (Soft seat)	-29 up to 270 (Soft seat)
	-29 up to 500 (Metal Seat)	-29 up to 500 (Metal Seat)	-29 up to 500 (Metal Seat)
	Down to -196 (Cryogenic)	Down to -196 (Cryogenic)	Down to -196 (Cryogenic)
END CONNECTION	Flanged, BW	Flanged, BW	Flanged, BW
FACE TO FACE	ASME B16.10	ASME B16.10	ASME B16.10
LEAKAGE CLASS	MSS SP 61	MSS SP 61	MSS SP 61
	API598	API598	API598
BODY MATERIAL	Carbon Steel	Carbon Steel	Carbon Steel
	Stainless Steel	Stainless Steel	Stainless Steel
	Alloy 20, Duplex	Alloy 20, Duplex	Alloy 20, Duplex
	Nickel-Aluminum Bronze	Nickel-Aluminum Bronze	Nickel-Aluminum Bronze
SEAT MATERIAL	METAL	METAL	METAL
FEATURES	FIRE SAFETY	FIRE SAFETY	FIRE SAFETY
	FUGITIVE EMISSION	FUGITIVE EMISSION	FUGITIVE EMISSION
	TIGHT SHUT OFF	TIGHT SHUT OFF	TIGHT SHUT OFF
	SPECIAL CLEANED SERVICE	SPECIAL CLEANED SERVICE	SPECIAL CLEANED SERVICE
	CRYOGENIC SERVICE	CRYOGENIC SERVICE	CRYOGENIC SERVICE
	TOXIC SERVICE	TOXIC SERVICE	TOXIC SERVICE
