Bronze Valve
AVAILABLE CLASS / SIZE
| TYPE | ANSI CLASS | ACTUATOR | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 150LB | 300LB | 600LB | 900LB | 1500LB | 2500LB | 4500LB | P | E | H | |
| GATE | ½” ~ 36” | ½” ~ 36” | - | - | - | - | - | ○ | ○ | ○ |
| GLOBE | ½” ~ 24” | ½” ~ 24” | - | - | - | - | - | ○ | ○ | ○ |
| CHECK | ½” ~ 36” | ½” ~ 36” | - | - | - | - | - | - | - | - |
| BALL | ½” ~ 36” | ½” ~ 36” | - | - | - | - | - | ○ | ○ | ○ |
| TYPE | GATE | GLOBE | CHECK | BALL |
|---|---|---|---|---|
| DESIGN | ASME B16.34 | ASME B16.34 | ASME B16.34 | ASME B16.34 |
| API 600 | API 523 | API6D | API6D | |
| MSS SP-80 | MSS SP-80 | MSS SP-80 | MSS SP-80 | |
| RATING | #150 up to #300 | #150 up to #300 | #150 up to #300 | #150 up to #300 |
| SIZE | ½” up to 36” | ½” up to 24” | ½” up to 36” | ½” up to 36” |
| TEMPERATURE(℃) | -29 up to 290 | -29 up to 290 | -29 up to 290 | -29 up to 290 |
| END CONNECTION | NPT, Flange | NPT, Flange | NPT, Flange | NPT, Flange |
| FACE TO FACE | ASME B16.10 | ASME B16.10 | ASME B16.10 | ASME B16.10 |
| LEAKAGE CLASS | API598 | API598 | API598 | API598 |
| BODY MATERIAL | Nickel-Aluminum Bronze / Bronze | Nickel-Aluminum Bronze / Bronze | Nickel-Aluminum Bronze / Bronze | Nickel-Aluminum Bronze / Bronze |
| SEAT MATERIAL | METAL | METAL | METAL | PTFE, RTFE, PEEK, METAL |
| FEATURES | FIRE SAFETY | FIRE SAFETY | FIRE SAFETY | FIRE SAFETY |
| FUGITIVE EMISSION | FUGITIVE EMISSION | FUGITIVE EMISSION | FUGITIVE EMISSION | |
| TIGHT SHUT OFF | TIGHT SHUT OFF | TIGHT SHUT OFF | TIGHT SHUT OFF | |
| SPECIAL CLEANING SERVICE | SPECIAL CLEANING SERVICE | SPECIAL CLEANING SERVICE | SPECIAL CLEANING SERVICE |
